1000 kg
1000 kg
1100 mm
1100 mm
570 mm
570 mm

Description

The electric hand stacker provides you with a cost-effective aid for performing occasional stacking operations as well as loading and unloading commercial vehicles. With a capacity of 1000 kg, the HC 110 also serves as a useful work table, for example, for keeping goods or individual parts to hand at an ergonomic height.

  • Lift height of 1600 or 2500 or 3000 mm
  • Powerful 1.5 kW lift motor
  • Maintenance-free lead-gel battery – no time-consuming water replenishment
  • On-board charger for simple charging
  • Steering castors with foot protection
  • Mechanical parking brake for secure parking

Semi-electrical hand stacker for electric lifting and manual transport

This electric hand stacker delivers premium Jungheinrich quality for optimum durability. The HC 110 represents a cost-effective alternative to motorised devices for occasional stacking and retrieving at lift heights up to 3000 mm. The HC 110 with 1000 kg capacity is moved manually and raises goods with a 1,5 kW lift motor. It has a wide range of uses and even serves as an effective work or lift table.

The electric hand stacker impresses with its safe and easy operation. During transport, you simply pull the load via the long tiller. The ergonomic guide handles ensure effortless pushing and manoeuvring when stacking and retrieving. The foot protection on the steering castors provides additional protection. The mechanical, foot-operated parking brake allows you to park the stacker securely at any time.

The electro-hydraulic lift control and easy accessibility of the lift and lower buttons ensure precise fork positioning. All controls and displays are clearly arranged for maximum usability. The transparent Plexiglas panel within the steel frame offers protection against falling objects, prevents accidental reaching through the mast and ensures a clear view in travel direction at all times.

The maintenance-free lead-gel battery eliminates the need for time-consuming water replenishment. The battery discharge indicator permanently shows the current battery condition. The high-frequency on-board charger with charge status indicator enables convenient charging at any 230 V socket.

Order the HC 110 electric hand stacker from our web shop.

Type
Hand pallet truck with high lift
Drive
Manual
Operator type
Pedestrian
Capacity (Q)
1000 kg
Load centre distance (c)
600 mm
Net weight incl. battery
348 kg (lift 1600 mm)
435 kg (dvig 2500 mm)
450 kg (dvig 3000 mm)
Lift range
85 - 1600 mm
85 - 2500 mm
85 - 3000 mm
Lift (h3)
1600 mm
2500 mm (ZT 2500)
3000 mm
Tiller height
1156 mm
Overall length (l1)
1720 mm
Face of forks length
620 mm
Overall width (b1)
777 mm
Fork length (l)
1100 mm
Fork height (s)
60 mm
Fork width (e)
180 mm
Width across forks (b5)
570 mm
Support arm length
970 mm
Support arms outer distance
520 mm
Aisle width
2175 mm
Turning radius (Wa)
1335 mm
Lift motor, performance with S3
1,5 kW
Lift speed with/without load
0,08 / 0,11 m/s
Lowering speed with/without load
0,19 / 0,13 m/s
Brake
Parking brakes
Battery type
Lead gel battery
Battery voltage
12 V/per unit
Battery capacity
150 Ah/per unit
Battery weight
45 kg
Charger
Integrated
Drive wheel material
Polyurethane (PU)
Drive wheel diameter
180 mm
Drive wheel width
50 mm
Fork roller material
Nylon
Fork roller diameter
74 mm
Fork roller width
93 mm
Fork roller equipment
Single
Display
Discharge indicator
Hydraulic
One-step

Jungheinrich HC 110, capacity 1000 kg

Electric lifting and manual transport – for occasional stacking requirements

  • Powerful 1.5 kW lift motor
  • Maintenance-free lead-gel battery
  • On-board charger for simple charging

€3,400.00
Tax excluded
51129490
Status: Out of stock

Delivery time: Please contact us for information about the delivery time.
